Corning 004EEC-13122A20

**Product Name:** Corning 4-Core Single Mode Outdoor Armoured Fiber Optic Cable – 004EEC-13122A20

**Brand:** Corning

**Model / Part Number:** 004EEC-13122A20

**Product Type:** Outdoor Fiber Optic Cable

**Fiber Count:** 4 Core

**Fiber Type:** Single Mode OS2

**Fiber Specification:** 9/125 µm, SMF-28e+

**Fiber Standard:** ITU-T G.652.D

**Cable Construction:** Central Loose Tube, Steel Tape Armoured

**Cable Design:** A-DQ(ZN)(SR)2Y

**Outer Jacket Material:** Linear Low-Density Polyethylene (LLDPE)

**Outer Jacket Colour:** Black

**Nominal Outer Diameter:** 7.5 mm

**Buffer Tube Diameter:** 3 mm

**Fiber Colour Coding:** Blue, Orange, Green, Brown

**Maximum Attenuation:**
- 1310 nm: 0.36 dB/km
- 1383 nm: 0.36 dB/km
- 1550 nm: 0.22 dB/km

**Crush Resistance:** 2000 N/10 cm

**Minimum Bend Radius During Installation:** 150 mm

**Minimum Bend Radius During Operation:** 110 mm

**Maximum Installation Tensile Strength:** 1000 N

**Installation Temperature:** -5°C to +50°C

**Applications:** Outdoor fiber-optic backbone networks, building-to-building connectivity, telecommunications infrastructure, ISP networks and duct installations.

**Key Features:**
- Four single-mode optical fibers
- Steel tape armour for enhanced mechanical protection
- Outdoor polyethylene jacket
- Suitable for long-distance data transmission
- Low optical signal attenuation
- Water-resistant cable construction
- Suitable for telecommunications and enterprise network infrastructure

**EAN / GTIN:** 4042673580669
