DINSTAR UC200 PRO

Dinstar UC200 Pro

Model: UC200 Pro
Product Type: IP PBX / VoIP Phone System
Application: Small & Medium Businesses (SMEs)

SIP Users: 60 / 200 / 500
Concurrent Calls: 15 / 30 / 50
Concurrent Calls with Full Recording: Up to 25
FXS Ports: 2
FXO Ports: 2
Maximum FXS Ports: 8
Maximum FXO Ports: 8
Expansion Slots: 3
Expansion Modules: 2S / 2O / 1S1O
Gigabit Ethernet Ports: 2
USB: 1 × USB 2.0
Console: 1 × USB-B
TF Card Slot: 1

SIP Trunks: Supported
SIP Extensions: Supported
IP Phone Auto Provisioning: Supported
Built-in VPN: VPN Server / Client
Voicemail: Supported
Voicemail to Email: Supported
IVR: Multi-level / Multi-language / Time-based
Auto Attendant: Supported
Call Queue: Supported
Ring Group: Supported
Call Recording: Supported
Paging / Intercom: Supported
3-Way Conference: Supported
Video Calling: Supported
Call Forwarding: Supported
Call Transfer: Supported
Call Parking: Supported
Call Pickup: Supported
Follow Me: Supported
DID: Supported
Music on Hold: Supported
CDR: Supported
Flexible Routing: Supported
Failover Routing: Supported
Time-based Routing: Supported
Caller/Called Number Manipulation: Supported
FAX: T.30 / T.38
LDAP: Supported
WebRTC: Supported
PMS Integration: Supported
Attendant Console: Supported

Security: IP Firewall, Fail2ban, ACL, Blacklist/Whitelist, Anti-brute-force protection
Encryption: TLS, SRTP, ZRTP
Management: Web-based management interface
Remote Management: Supported
Configuration Backup/Restore: Supported
Firmware Upgrade: HTTP / HTTPS / TFTP / FTP
Network Management: Dinstar NMS

Local Recording: USB storage supported
Power Supply: 12VDC, 2A
Power Consumption: 10W
Operating Temperature: 0°C to 40°C
Storage Temperature: -10°C to 90°C
Humidity: 10%–90% RH, non-condensing
Dimensions: 260 × 154 × 42 mm
Weight: 1.1 kg

The UC200 Pro can also be expanded with up to three additional 2S, 2O or 1S1O modules, allowing the analog FXS/FXO capacity to be increased as required.
